Luminaire body material: 6061 aluminum (processed by CNC technology)
●
U-shaped bracket material: Stainless steel
●
Base-mounted type material: Die-cast aluminum
●
All brackets are equipped with a graduated scale and a mechanical aiming lock
●
Anti-glare louvers are designed for different optics
●
Luminaire surface color: Matte gray
Protection & Performance Ratings
●
IP rating: IP65
●
IK rating: IK07
●
LED chip brands: Cree, Bridgelux, Luminus (selected based on the optical and chip requirements of different luminaires)
●
Standard color temperatures: 2700K, 3000K, 4000K, 6000K, RGB, RGBW
●
Color Rendering Index (CRI): ≥90
●
MacAdam Step: ≤3
●
Lifetime: 100,000h - L80 - B10 (at Ta = 40°C; i.e., 80% luminous flux retention with a 10% failure probability at an ambient temperature of 40°C)
●
Operating ambient temperature range: -20°C ~ 50°C
Electrical & Control Specifications
●
Operating voltage options: DC24V,AC220V (AC220V only for non-dimmable version)
●
Power cable specifications:
●
AC220-240V: 3×1mm²
●
DC24V (＜50W): 2×0.75mm²
●
DC24V (＞50W): 2×1mm²
●
DC24V (1W): 2×0.5mm²
●
Luminaire control options: Build in ON/OFF\ 0-10V,dimmable DMX512 driver
●
Output power cable length: The luminaire is equipped with a 300mm or 500mm long output power cable; specifications must be specified when placing an order
Mounting Accessories
●
U-bracket, Spike for ground, Arc-shaped plate, Hoop
